| 牌号简介 About |
|---|
| Bormed™ SC820CF是一种非常软的无规异相共聚物。该牌号适用于冷轧管式水淬薄膜和无取向薄膜的生产。 Bormed SC820CF is a soft random heterophasic copolymer. The current version of Bormed SC820CF has been scheduled for deletion. Please refer to Bormed SC820CF-11 documentation for new projects. In case of questions, please contact either your responsible Borealis Sales Manager and/or Application Development Engineer. This grade is suitable for the manufacturing of non-oriented cast films on chill roll process and blown film on tubular water quenching process. CAS-No.: 9010-79-1 Applications Bormed SC820CF has been evaluated according to different regulations and norms. Typical applications are mentioned below for Medical devices or Pharmaceutical & Diagnostic packaging. However, Borealis should be consulted for final approval to evaluate the use of Bormed SC820CF . Medical device packaging Pouches for IV solutions Pouches for Continuous Ambulatory Peritoneal Dialysis Secondary packaging This grade may only be used for the applications listed in the Product Datasheet and only to the extent that the application is within the scope of the tests set out in the Statement on Compliance to Regulations on Medical Use for that grade. If an application is not listed in the Product Datasheet, the grade can be used for such application only after express written consent of the Borealis Marketing Manager, Healthcare. Borealis prohibits the use of any healthcare grade product in an implantable device that is introduced into the human body by surgical intervention and that is intended to remain in place following surgical procedure. Special features High gloss High toughness at low temperatures High softness Sterilisability by means of water steam Low haze High water vapour barrier High impact strength at 23 °C |
产品描述 Product Description
用途：医用包装;管件;
加工条件：薄膜挤出 Film extrusion
性能特点： 可回收; 透湿性差; 蒸汽消毒; 柔软性好; 透光性好; 冲击性能好; 表面光泽度好; 韧性好; 易加工; Excellent Processability,Good Clarity,Good flexibility,Good surface appearance,High impact resistance,Steam sterilized,Renewable resources,Poor moisture permeability,Soft
| 技术参数 Technical Data | |||
|---|---|---|---|
|
物理性能 PHYSICAL |
额定值 Nominal Value |
单位 Units |
测试方法 Test Method |
|
熔体质量流动速率 Melt Flow Rate |
|||
|
230℃，2.16kg 230℃，2.16kg |
3.9 | g/10min | ISO 1133 |
|
机械性能 MECHANICAL |
额定值 Nominal Value |
单位 Units |
测试方法 Test Method |
|
弯曲模量 Bending modulus |
|||
|
23℃，注塑成型 23 ℃, injection molding |
550 | MPa | ISO 178 |
|
摩擦系数 friction coefficient |
> 0.70 | ISO 8295 | |
|
薄膜 film |
额定值 Nominal Value |
单位 Units |
测试方法 Test Method |
|
薄膜厚度 film thickness |
|||
|
测试 test |
50 | µm | |
|
拉伸模量 Tensile modulus |
ISO 527-3 | ||
|
MD，50 µm MD，50 µm |
330 | MPa | ISO 527-3 |
|
TD，50 µm TD，50 µm |
MPa | ISO 527-3 | |
|
拉伸强度 tensile strength |
ISO 527-3 | ||
|
MD，50 µm MD，50 µm |
MPa | ISO 527-3 | |
|
TD，50 µm TD，50 µm |
MPa | ISO 527-3 | |
|
拉伸应变 Tensile strain |
ISO 527-3 | ||
|
MD，断裂，50 µm MD, fracture, 50 µ m |
% | ISO 527-3 | |
|
TD，断裂，50 µm TD, fracture, 50 µ m |
% | ISO 527-3 | |
|
装有测量仪表的落镖冲击 Dart impact equipped with measuring instruments |
|||
|
50 µm，Total Energy 50 µm，Total Energy |
J | ISO 7765-2 | |
|
热性能 THERMAL |
额定值 Nominal Value |
单位 Units |
测试方法 Test Method |
|
熔融温度 Melting temperature |
℃ | ISO 11357-3 | |
|
光学性能 optical performance |
额定值 Nominal Value |
单位 Units |
测试方法 Test Method |
|
光泽度 gloss |
|||
|
20°，50 µm 20°，50 µm |
ASTM D2457 | ||
|
雾度 Haze |
|||
|
50 µm 50 µm |
% | ASTM D1003 | |
| 备注 |
|---|
| 1 一般属性：这些不能被视为规格。 |
|
