牌号简介 About |
---|
这种以聚酰胺12为基础的白色细粉PA 2200具有很好的平衡性能,适用范围广泛。由PA 2200制成的激光烧结零件具有优异的材料性能:高强度和硬度、良好的耐化学性、优异的长期恒定性能、高选择性和细节分辨率、各种表面处理可能性(例如,金属化、炉搪瓷、振动研磨、桶着色、粘合、粉末涂层、植绒)。符合EN ISO 10993-1和USP/VI/121°C的生物相容性,符合欧盟塑料指令2002/72/EC(高酒精食品除外)的食品接触批准。材料的典型应用是具有最高质量的全功能塑料部件。由于其优良的力学性能,该材料经常被用来代替典型的注塑塑料。生物相容性允许其用于假体,高耐磨性允许实现可移动部件连接。120微米层厚:平衡参数设置的优点是平衡。120微米的层厚在生产成本、机械性能、表面质量和精度之间提供了完美的平衡。因此,它适用于具有不同几何形状、尺寸和要求的零件。 This whitish fine powder PA 2200 on the basis of polyamide 12 serves with its very well-balanced property profile a wide variety of applications. Laser-sintered parts made from PA 2200 possess excellent material properties: high strength and stiffness good chemical resistance excellent long-term constant behaviour high selectivity and detail resolution various finishing possibilities (e.g. metallisation, stove enamelling, vibratory grinding, tub colouring, bonding, powder coating, flocking) bio compatible according to EN ISO 10993-1 and USP/level VI/121 °C approved for food contact in compliance with the EU Plastics Directive 2002/72/EC (exception: high alcoholic foodstuff) Typical applications of the material are fully functional plastic parts of highest quality. Due to the excellent mechanical properties the material is often used to substitute typical injection moulding plastics. The biocompatibility allows its use e.g. for prostheses, the high abrasion resistance allows e.g. the realisation of movable part connections. 120 µm layer thickness: The advantage of the Balance parameter set is equilibrium. The layer thickness of 120 µm offers a perfect balance between production costs, mechanical properties, surface quality and accuracy. It is therefore suitable for parts with varying geometries, dimensions and requirements. |
技术参数 Technical Data | |||
---|---|---|---|
物理性能 PHYSICAL |
额定值 Nominal Value |
单位 Units |
测试方法 Test Method |
密度 Density |
0.930 | g/cm³ | 内部方法 |
Thickness(Layer) Thickness(Layer) |
120.0 | µm | |
冲击性能 IMPACT |
额定值 Nominal Value |
单位 Units |
测试方法 Test Method |
简支梁缺口冲击强度 Charpy Notched Impact Strength |
|||
23℃ 23℃ |
4.8 | kJ/m² | ISO 179/1eA |
简支梁无缺口冲击强度 Charpy Unnotched Impact strength |
|||
23℃ 23℃ |
53 | kJ/m² | ISO 179/1eU |
悬臂梁缺口冲击强度 Izod Notched Impact strength |
|||
23℃ 23℃ |
4.4 | kJ/m² | ISO 180-1A |
热性能 THERMAL |
额定值 Nominal Value |
单位 Units |
测试方法 Test Method |
维卡软化温度 Vicat Softening Temperature |
|||
B50 B50 |
℃ | ISO 306 | |
熔融温度 Melting temperature |
℃ | ISO 11357 | |
机械性能 MECHANICAL |
额定值 Nominal Value |
单位 Units |
测试方法 Test Method |
邵氏硬度 Shore hardness |
|||
邵氏 D,15 秒 Shore D, 15 seconds |
ISO 868 | ||
拉伸模量 Tensile modulus |
MPa | ISO 527-2 | |
拉伸强度 tensile strength |
|||
-- -- |
MPa | ISO 527-2 | |
-- -- |
MPa | ISO 527-2 | |
拉伸应变 Tensile strain |
|||
断裂 fracture |
% | ISO 527-2 | |
断裂 fracture |
% | ISO 527-2 | |
弯曲模量 Flexural Modulus |
|||
23℃ 23℃ |
MPa | ISO 178 |
备注 |
---|
1 一般属性:这些不能被视为规格。 |
2 X Direction |
3 Z Direction |
4 Y Direction |
